Arrow MLX Series Grade 2 Lever Locksets

SKU # ARMLX

Arrow MLX Series is a robust BHMA Grade 2 lockset featuring a freewheeling lever for abuse resistance, two-screw lock install for quick installation and a 10 year mechanical warranty.

Pricing varies based on options selected below.

US$58.10

Finish *
Backset *
Function *
Keyway *

Qty:

Clear All

Specifications:

Door Preparation: Cold rolled steel with zinc dichromate finish for corrosion resistance. Latch retractor is precision cast steel. Requires standard 2-1/8" (53.97 mm) bore through door
Backset: 2-3/4" (69.85 mm) backset standard
Door Thickness: 1-3/8" (34.92 mm) to 1-3/4" (44.45 mm) standard
Latch: Stainless Steel 1/2" (12.7mm) throw, UL Listed, guarded latchbolt on all locking functions
Latch front: 1-1/8" x 2-1/4" for 2-3/4" (69.85mm) backset
Strike: 4-7/8" ANSI (123.83mm)
Handing: Non handed
Freewheeling Lever
Exposed Trim: MLX Levers are pressure cast zinc measuring 4-3/4" (120.65mm) in length.MLX Roses are wrought brass 3-11/32" (84.8mm) diameter. Total projection from face of door is 2-17/32" (64.5mm)
Cylinder: Solid brass 6 pin, Schlage CS keyway, SFIC and SIC
Keys: 2 brass keys
Finish: US3, US26D.
