Inox DC6126LCVAL Cmrcl Clsr Grd 1 Adj Range 2-6 Less Cvr AL
Specifications
DC6114 Power Size: 1 through 4
DC6126 Power Size: 2 through 6
Body: One-piece aluminum alloy body with rack & pinion design
Pressure Valves: Separate and independent latch, sweep, and back-check pressure valves
Handing: Non-handed; can be installed on either left- or right-handed swing doors
Cover: Standard Closer comes Less Cover
Piston: 34mm (1-11/32") diameter
Pinion Shaft: 16mm (5/8") diameter
Projection: 66.7mmm (2-5/8") without cover
Door Swing: Standard arm applications with covers allow doors up to 180° swing
Compliance
- ANSI/BHMA A156.4 Grade 1 Closers
- ANSI A117.1 ADA Accessibility (DC6114 Only)
- UL Listed for ANSI/UL10B and UL10C
- CAN/ULC S104 up to 3 Hours UL 228 UBC Standard 7-2 (1997)
- NFPA 252 NFPA 80 National Fire Protection - Fire Door Assembly
- NFPA101 National Fire Protection - Life Safety
- ANSI/BHMA A156.18 Finishes
Regular / Parallel Arm
Regular arm with adjustable slider for wide range of frame conditions. Can be mounted to hinge (pull) side or top jamb
For parallel arm, mount bracket mount on top of frame on push side of door. Frame should be reinforced for bracket
Hold Open Arm
DCAMHO
Adjustable round slide arm for wide range of frame conditions. Can be mounted with parallel bracket
Cush Arm
DCAMCUSH
Heavy duty forged arm with cush stop, parallel arm mount. Mount using frame reinforcement in stop
Hold Open Cush Arm
DCAMHCUSH
Heavy duty forged arm with cush stop and hold-open parallel arm mount. Handle controls hold open function. Mount using frame reinforcement in stop
Sliding Track
Single lever (track) arm with surface-mounted closer for interior use on narrow-head frames and top rails. Three mounting positions
