Rockwood 2805-US26D Self Latching Top Bolt Only

SKU # RO/2805-26D

The Rockwood 2805-US26D Self Latching Top Bolt Only is a Self Latching Top Bolt Only.

Features include:
  • Self Latching Top Bolt Only
  • For metal doors
  • Automatically engages when the inactive door closes.
  • When the active door is opened, the inactive door stays latched at the top until the top bolt is released by pressing the plunger button on the bolt face.
  • UL Listed
  • Fasteners: 8 ea. #8 x 3/4" FH combo screws Note: No plastic anchor required
  • Size: 1" x 6-3/4"
  • Weight: 1.2 lbs
  • ANSI A156.3: Type 27
  • Satin Chrome Plated
US$62.98

Description:

Description:

Rockwood 2805-US26D Self Latching Top Bolt Only

The 2805 Combination Flush Bolt (Self Latching Top Bolt Only) is for use on select fire rated metal doors. This product automatically engages when the inactive door closes, and when the active door is opened, the inactive door stays latched at the top until the top bolt is released by pressing the plunger button on the bolt face.

  • No plastic anchor required
  • For Fire Rated Metal Doors labeled A, B, C, D & E up to 4'w x 8'h
  • Inactive door stays latched at top until bolt is released by pressing plunger button
  • Automatically engages when the inactive door closes

Specifications

  • Base Material: Brass, Stainless Steel
  • Fastener: 8 ea. #8 x 3/4" flat head combo screws. No plastic anchor required.
  • Weight: 1.2lbs.
  • Top Bolt Length: 6 3/4"
  • Top Bolt Width: 1"

Specifications:

Specifications:

Click Here for Rockwood Architectural Catalog
