RCI Rutherford Controls TD2
Delayed Unlock-Auto Relock Timer Board
STANDARD FEATURES
- 5 Modes of Operation:
- Delay on Operation
- Delay on Release
- Latching
- Pulsing
- Window
- Time range adjustable from 1 second to 34 hours
- 12 or 24VDC operation
- DPDT Relay output rated for 5A @ 24VDC
- LED status indicator relay
- Quartz controlled microprocessor
- Negative Trigger
Dimensions:
Length: 3.000" 76mm
Width: 2.000" 51mm
Height: 0.875" 22mm
Current Consumption - Active: 60mA
Current Consumption - Idle: 12mA
Relay Rating: 5A @ 24VDC
Environmental:
Product is not for use in outdoor environments.
