RCI 8375-28 Electromagnetic Locks
The 8375 Surface MicroMag® is uniquely small, measuring 6-17/32"W x 1-1/2"H x 13/16"D. This electromagnetic lock may be a compact design, but with a holding force of up to 300lbf it doesn’t lack strength. The RCI 8375 Surface MicroMag® is a secure locking solution for swinging doors on small enclosures.
Energy: 360mA Field-Selectable 12/24VDC (Max at 12VDC)
Strength: Up to 300lbf Holding Force
Warranty: Lifetime Limited Warranty
Mode: Fail-Safe
Technical Details
Dimensions: 6-17/32"W x 1-1/2"H x 13/16"D (166mm x 38mm x 21mm) – Includes 1/8" (3mm) mounting bracket
Armature Plate: 5-1/8"W x 1-1/4"H x 21/64"D (130mm x 32mm x 8.5mm)
Designed to overcome residual magnetism
Hardened steel armature nut
Self-drilling Teks® fasteners
Includes 21/64" (8.5mm) armature plate
Brushed Anodized Aluminum (28) finish
Applications
Cash drawers
Drug cabinets
Filing cabinets
Safes
Vending machines
Access cover hatches
